DAX (not available anymore)
- Convert digital outputs to analog outputs with the optional DAX (D/A eXtra) hardware add-on. Control up to four more amplifiers. Monitor seal formation, set holding potentials, motitors cell characteristics, sychronous episodic delivery. DAX hardware simply connects to the digital out BNCs. The single male BNC connects to ch0, the attached white wire connects to ch1, and the other four BNC assemblies attach to any of the digital out channels ch2-5. A 4.5 - 5 volt power source (central pin positive) drives the DAX. Output from each channel is +/- 5 volts.
